SCHAUBLIN F20 Push-Type Collet – Hexagonal / 76-00201
SCHAUBLIN F20 Push-Type Collet – Hexagonal / 76-00201
SCHAUBLIN F20 Push-Type Collet – Hexagonal / 76-00201
SCHAUBLIN F20 Push-Type Collet – Hexagonal / 76-00201

SCHAUBLIN F20 Push-Type Collet – Hexagonal / 76-00201

CHF 180.00
CHF 180.00
excl. VAT
SKU: 76-00201S04.0

Supplier : Heidi | Shop

Brand : Schaublin RBC

In stock – ships within 2 to 3 days

Reply within 48 business hours

Product information

Description

SCHAUBLIN F20 Push-Type Collet – Hexagonal / 76-00201

SCHAUBLIN Push Collet – Type F

The Type F push-type collet is designed for precise axial clamping of tools or workpieces. Clamping is achieved by pushing the collet into its housing using a nut or a tapered sleeve.

Type: F – Push-Type Collet

Smooth round bores up to 8.99 mm, grooved from 9 mm onward.
Smooth profile bores up to 13.99 mm, grooved from 14 mm onward.
Other versions available on request: e.g., knurled, hexagonal, etc.

Note: When not clamped, the collet is slightly open. The bore diameter must not be measured in this state.

Shipping, customs and returns

Where your order ships from. All our shipments leave Switzerland, from our warehouse in Val Terbi. International orders are consolidated at our premises, then sent as a single parcel.

Carrier. UPS worldwide, Swiss Post for deliveries within Switzerland. A tracking number is sent to you as soon as the parcel leaves.

Lead time. The dispatch time for this item is shown higher up on this page. Transit time is added to it and depends on the destination.

Customs and import taxes. Our prices are shown excluding VAT. For deliveries outside Switzerland, customs duties and import taxes are not included: they are collected by the carrier on delivery and remain payable by the recipient.

Returns. Right of return within 30 days. The terms are set out in our refund policy.

An oversized part or a special shipment? Request a quote and we will reply within 48 business hours.
