SER-TECK - STHM F20-87 (138E) LN15 ultra precise

$384.00 USD
$384.00 USD
excl. VAT
SKU: ST00537-D00.30/UP

Supplier : SER-TECK

Brand : Ser-Teck

In stock – ships within 2 to 3 days

Reply within 48 business hours

Product information

Description

SER-TECK - STHM F20-87 (138E) LN15 ultra precise

Carbide bore gauge with long nose, designed for ultra-precise bore measurements. Features an ultra-fine honed bore and 1/100 mm chamfer break, delivering maximum accuracy of 3 µm.

Features

  • Carbide body
  • Long nose for deep access
  • Ultra-fine honed bore
  • 1/100 mm chamfer break
  • Accuracy: ≤ 3 µm
Specifications

Main specifications

Material
Hardened steel, Carbide
Machining and production operations
Turning, Milling, Drilling, Tapping, Boring, Threading
Bar turning and microtechnology operations
CNC Machining, High-Speed Machining, Multi-Axis Bar Turning, Precision Machining
Documentation
Download documentation (PDF)
