Cast iron 4-jaw faceplate – DIN 55026

CHF 1,306.00
CHF 1,306.00
excl. VAT
SKU: 106-605

Supplier : Heidi | Shop

Brand : Niederhauser

On order – delivery in 10–15 business days

Reply within 48 business hours

Product information

Description

Niederhauser faceplate with 4 independent jaws for clamping non-cylindrical, off-centre or irregularly shaped workpieces. Each jaw is adjusted separately for precise centring.

Good to know: Mounts directly on a DIN 55026 (ASA type A) spindle nose – no backplate needed. Choose the taper size of your spindle.

  • Mounting: short taper DIN 55026 / 55021, front mounting
  • Body: cast iron
  • Jaws: one-piece, reversible and individually adjustable
  • Compatible with: lathe spindles with DIN 55026 nose (ASA type A)
  • Sizes: ø 200 to 800 mm, tapers 4 to 15

Supplied with: hard reversible jaws, 1 chuck key, 1 set of fixing screws.

Plate øTaper sizeDFArticle code
ø 200 mmTaper 463.525 mm82.6 mm106-604
ø 200 mmTaper 582.757 mm104.8 mm106-605
ø 200 mmTaper 6106.39 mm133.6 mm106-606
ø 250 mmTaper 463.525 mm82.6 mm106-704
ø 250 mmTaper 582.757 mm104.8 mm106-705
ø 250 mmTaper 6106.39 mm133.4 mm106-706
ø 250 mmTaper 8139.735 mm171.4 mm106-708
ø 315 mmTaper 582.757 mm104.8 mm106-805
ø 315 mmTaper 6106.39 mm133.4 mm106-806
ø 315 mmTaper 8139.735 mm171.4 mm106-808
ø 400 mmTaper 6106.39 mm133.4 mm106-906
ø 400 mmTaper 8139.735 mm171.4 mm106-908
ø 400 mmTaper 11196.885 mm235 mm106-901
ø 500 mmTaper 6106.39 mm133.4 mm106-956
ø 500 mmTaper 8139.735 mm171.4 mm106-958
ø 500 mmTaper 11196.885 mm235 mm106-951
ø 500 mmTaper 15285.795 mm330.2 mm106-955
ø 630 mmTaper 8139.735 mm171.4 mm106-108
ø 630 mmTaper 11196.885 mm235 mm106-111
ø 630 mmTaper 15285.795 mm330.2 mm106-115
ø 800 mmTaper 8139.735 mm171.4 mm106-208
ø 800 mmTaper 11196.885 mm235 mm106-211
ø 800 mmTaper 15285.795 mm330.2 mm106-215

Other sizes on request. Produced by Niederhauser.
